Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

  • 1
  • 2
  • 3

Brand Name : DUALRAYS

Model Number : DR-SPL300-FG2

Certification : CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available

Place of Origin : Shenzhen,China

MOQ : 5pcs

Price : negotiable

Delivery Time : 5-15 Bussiness Day

Packaging Details : Netural Package/OEM and ODM Package Available

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50000PCS/Month

Rated Wattage : 300W

Input : AC90~305V

Efficiency : 140lm/W

Life span : 50 000hrs

Beam : 30°/60°/90°

CCT : 3000-6500K

Contact Now

300W Outdoor Tennis Courts Led Flood Lights IP 65 Waterproof High Output Lighting Efficiency

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
* Aiming device Laser Pointer;
* 30°/60°/90° beam angle for options;
* 400W 45000lm, for 800W MHL equivalent;
* ±360° adjustable bracket;
* TM21(L80>50000hrs);

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Model No. DR-SPL300-FGXP DR-SPL400-FGXP DR-SPL600-FGXP DR-SPL800-FGXP
System Watts/W 300W 400W 600W 800W
System Efficiency/LPW 150LPW
Lumen Output/lm 45.000±5% 60.000±5% 90.000±5% 120.000±5%
Rated Input Voltage/V AC100~277V, 50/60Hz
LEDs Light Source SMD5050
SDCM <5
CCT/K 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra >70Ra (>80Ra for Option)
Power Factor >0.95
THD <10%
Beam Angle(Optional) 30°/60°/90°
UGR <25
Surge Protection 4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver Meanwell ELG / HLG Optional
IP Rating IP65
Dimming(Optional) 1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time 0.5s
Protection Class ClassⅠ
Finishing Color(Optional) Black RAL9017(Standard) / White RAL9016 Optional
Material Aluminum+PC
Lifespan/hrs 70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃ 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃ - 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Character/Power
300W
400W
600W
800W
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAAPrivate Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
A / mm
Ø445
Ø445
Ø537
Ø537
B / mm
321
321
373
373
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-SPL300-FGXP
12.4
610*510*250
13.8
1PCS/CTN
DR-SPL400-FGXP
12.9
610*510*250
14.7
1PCS/CTN
DR-SPL600-FGXP
25.3
890*710*275
27.6
 1PCS/CTN
DR-SPL800-FGXP 25.9 890*710*275 28.8
1PCS/CTN


Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA


Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA

(DIALUX Simulation)
　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　　
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
(Partnership)
Private Modular LED Sports Ground Flood Lights Laser Pointer 5 Years Warranty With CE ROHS SAA
